3 Cavity Puv Tuaj Tshuab Raj Tshuab Rau Lub Raj Mis Loj
1.Cov khoom Cov Nta
OGB-3-10S lub raj mis ua tshuab tuaj yeem tshuab 3-10L dej fwj lossis roj fwj.
Kev nqes tes rau lub raj mis pwm ua rau kev teeb tsa ua tau yooj yim dua.
Kov lub vijtsam tswj kev kaw haujlwm rau kev ua haujlwm yooj yim nrog 9inch siemens LED npo.
Cov teeb tsa hluav taws xob sib txig sib txig sib txig muaj lub teeb sib zog, preforms tau muab rhaub kom zoo ib yam thaum tig, PLC lossis hluav taws xob siab hloov kho lossis tswj txhua pawg kub.
2. khoom lag luam specification
| OGB-3-10S | ||||
KHOOM | Kev xav tso tawm | PSC / H | 1800 | |
| Max ntim | L | 10.0 | ||
| Max qhov siab | hli | 360 | ||
| Max taub | hli | 195 | ||
PWM | Kab noj hniav | / | 3 | |
| Pwm phaj qhov ntev (LxH) | hli | 840x360 | ||
Pwm tuab | hli | 280 | ||
Pwm qhib stroke | hli | 220 | ||
LUS QHIA | Lub Zog | kw | 220-380v / 50-60hz | |
| Tag nrho cov hwj huam | kw | 35 | ||
| Cua sov fais fab | kw | 32 | ||
| CUA SYSTEM | Cov sijhawm ua haujlwm siab | Mpa | 0.8-1.0 | |
| Ua pa noj | m³ / feeb | ≥1.6 | ||
| Tshuab pa tawg | Mpa | 2.6-4.0 | ||
| Tshuab noj cua | m³ / feeb | ≥3.2 | ||
TSHUAB | Blower dimension (LxWxH) | m | 4..5x1.9x2.0 | |
| Ntshav ceeb thawj | KG | 3200 | ||
Cub qhov ntev (LxWxH) | m | 1.9x1.9x2.2 | ||
| Qhov cub hnyav | KG | 200 | ||
3.Botle qauv
dej, haus, dej tshuaj yej,siv tau roj, kev saib xyuas kev noj qab haus huv khoom.pharmaceutical, thaj chaw khoom noj khoom haus.
4. Tshuab cov ntsiab lus
5.Daim ntawv pov thawj
ISO9001 ， CAS, CE thiab lwm yam.
6.Xyuas
OUGE tuaj yeem muab cov khoom zoo rau koj, cov khoom lag luam zoo tshaj plaws ua sai sai pheej yig.Our lub raj mis& cov qauv kev pabcuam yog txhua lub raj mis tsim kev pabcuam uas pib nrog cov lus pom zoo rau kev tsim qauv thiab xaus rau thaum lub raj mis uas ua tau raws li koj cov kev qhia tshwj xeeb thiab cov nyiaj tau ntau. hauv cov ntaub ntawv los ntawm kev hnyav lub teeb.
Lub raj mis& cov phiaj xwm kev sib koom ua ke suav nrog cov theem hauv qab no:
Kev tsim kho cov tswv yim tsim thiab kev lag luam
Xaiv cov ntaub ntawv
Tsim pwm yas tsim
CAD thiab FEM-txhawb kev tsim kho
Kev tsim cov tshuab pwm
Cov txheej txheem tswj hwm
Cov khoom zoo tshaj plaws txuag （lub teeb tawm）
7.Shipping& tus me nyuam
Lub sij hawm them ：30% los ntawm T / T raws li tso nyiaj, qhov nyiaj yuav tsum tau them ua ntej ua zaub mov xa tuaj.
Muaj Cov Lus Cog Tseg TradeFOB, CFR, CIF, EXWetc.
Shipping ：Los ntawm hiav txwv / Los ntawm huab cua
Tus me nyuam lub sij hawm:30-45 hnub tom qab tau txais cov qhua tuaj noj mov thiab paub meej tias lub raj mis teeb tsa.
Warranty ：1 xyoos tom qab tshuab tuaj txog hauv lub khw Hoobkas.
8. Tiv toj peb
Cim npe nrov: 3 kab noj hniav puv lub raj mis blower rau lub raj mis roj loj, Suav teb, chaw tsim khoom, chaw muag khoom
